DSO1000B Series

60MHz-200MHz Bandwidth Oscilloscope;
1GSa/s sample rate, 1M Memory Depth, and 6000 Counts DMM with analog bargraph;
5.6 inch TFT Color LCD Display, high resolution(640*480).

OneDrive Download

High Bandwidth 60MHz-200MHz Oscilloscope, 1GS/s sample rate, and 6000 Counts DMM with analog bargraph.
1M Memory Depth.
High Refresh Rate (2500 frames).
Large 5.6 inch TFT Color LCD Display; High Resolution(640*480); Dual-Window Design --More clear, More Detailed.
One-touch automatic setup optimizes the position, range, timebase, and triggering to assure a stable display of virtually any waveform.
Easy-to-use pop-up menu with built-in multi-language help system.
32 Automatic Measurements.
Waveform Math: Add, Subtract, Multiply, and Divide.
Store and recall over.
Automatic cursor tracking measurements.
XY Mode.
Built-in FFT function converts a time-domain signal into its frequency components to measure harmonic content and distortion in systems.
Waveform Recorder to capture/replay input waveforms from CH1 and CH2 with a maximum record length of 1000 frames.
Pass/Fail function compares a stored waveform to an unknown input.
Average Mode for smoothing waveforms.
Square Wave Output (2V, 1kHz) for probe adjustment.
USB Host/Device 2.0 full-speed interface ,support removeable disk, LAN Optional ,Easy to control by PC or long-distance.
Dimensions (mm):240(L)x165(W)x50(H), be carried easily.

Function Picture

If connect to computer, it can be used as a virtual oscilloscope

Model	DSO1202B	DSO1102B	DSO1062B
Bandwidth	200MHz	100MHz	60MHz
Channel	2
Real-Sample Rate	1GSa/s
Equivalent Sample Rate	25GSa/s
Record Length	1M
Rish time	≤1.7ns/≤3.5ns/≤5.8ns
Timebase Accuracy	±50ppm
Time Base Range	2ns/div-40s/div / 4ns/div-40s/div / 4ns/div-40s/div
Input Impandance	1MΩ
VOLTS/DIV Range	2mV/div～5V/div
A/D Converter	8bit
Position Range	±50V(5V/div), ±40V(2V/div～500mV/div), ±2V(200mV/div～50mV/div), ±400mV(20mV/div～2mV/div)
DC Gain Accuracy	±3% for Normal or Average acquisition mode, 5V/div to 10mV/div; ±4% for Normal or Average acquisition mode, 5mV/div to 2mV/div
Bandwidth Limit	20MHz
Trigger Types	Edge, Video, Pulse, Slope, Over time, Alternative
Trigger Source	CH1, CH2,
Math	+,-,x,÷,FFT, Invert
Cursor Measurement	Voltage difference between cursors: △V; Time difference between cursors: △T; Reciprocal of △T in Hertz (1/ΔT);
Auto Measuerment	Frequency, Period, Mean, Pk-Pk, Cycli RMS, Minimum, Maximum, Rise time, Fall Time, +Pulse Width, -Pulse Width, Delay1-2Rise, Delay1-2Fall, +Duty, -Duty, Vbase, Vtop, Vmid, Vamp, Overshoot, Preshoot, Preiod Mean, Preiod RMS, FOVShoot, RPREShoot, BWIDTH, FRF, FFR, LRR, LRF, LFR, LFF
DMM Max. Resolution	6,000 Counts
Testing Modes	Voltage, Current, Resistance, Capacitance, Diode & Continuity
Max. Input Voltage	AC: 600V, DC: 800V
Max. Input Current	AC:10A , DC: 10A
Max. Input Impandance	10MΩ
Display	5.6"TFT 16K Color Display, 640*480 dots
Size	245mm x 163mm x 52mm
Weight	1.3KG(Without Package)
Standard Probe	PP200x2	PP150x2	PP80x2

Model	Bandwidth	Channels	Sampling rate	Other

DSO1000BV Series	60MHz-200MHz	2CH	1GSa/s	Video Help Function Bulit in 4G SD Card 6000 Counts DMM with analog bargraph 1M Memory Depth 5.6'' LCD (640*480) OSC and DMM electrical isolation
DSO1000B Series	60MHz-200MHz	2CH	1GSa/s	6000 Counts DMM with analog bargraph 1M Memory Depth 5.6 LCD (640*480) OSC and DMM electrical isolation
DSO1000S Series	60/120/150/200MHz	2CH	1GSa/s	Isoluted Channel 1M Memory Depth 6000 Counts DMM 5.6'' LCD (640*480) OSC and DMM electrical isolation
DSO8000 Series	60MHz	2CH	250MSa/s	Five in One oscilloscope /Spectrum Analysis/DMM Arb. Waveform Generator /Frenquency Counter 6000 Counts DMM OSC and DMM electrical isolation
DSO1000 Series	200MHz/60MHz	2CH	500MSa/s / 250MSa/s	6000 Counts DMM with analog bargraph 32K Memory Depth 5.7'' LCD (320*240) OSC and DMM electrical isolation
