HDG2000B Series

16Bit Resolution, 250MSa/s Sample Rate; 64M Memory Depth; 16 channels digital output, 7 inch, 64K true color TFT display, WVGA(800X480)

  • 16Bit Resolution, 250MSa/s Sample Rate; 64M Memory Depth;
  • 100/80/60/30/20/10MHz or 5MHz Max. Sine Output Frenquency;
  • 16 channels digital output, together with the analog channel can rebuild the more mixed signals in daily practice
  • Support AM, FM, PM, ASK, FSK, PSK and PWM modulations
  • TCXO timebase standard, OCXO optional for ultra-high stability
  • 7 inch, 64K true color TFT display, WVGA(800X480)
  • Plenty of interfaces: USB Host, USB Device, LAN
Model HDG2102B HDG2082B HDG2062B HDG2032B HDG2022B HDG2012B HDG2002B
Main Features
Channel 2 2 2 2 2 2 2
Memory Depth 64M 64M 64M 64M 64M 64M 64M
Frenquency 100MHz 80MHz 60MHz 30MHz 20MHz 10MHz 5MHz
Sample Rate 250MSa/s
Voltage Resolution 16Bit
Digital Output 16 Channels output
Frenquency Characteristic
Standard Waveforms Sine, Square, Ramp, Pulse, Noise, Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, Haver Sine, Lorentz, Dual-Tone, DC
Sine 1uHz~Max.
Square 1uHz~40MHz 1uHz~35MHz 1uHz~30MHz 1uHz~5MHz
Pluse 1uHz~30MHz 1uHz~25MHz 1uHz~25MHz 1uHz~5MHz
Ramp/Triangle 1uHz~4MHz 1uHz~3MHz 1uHz~3MHz 1uHz~30MHz 1uHz~20MHz 1uHz~10MHz 1uHz~5MHz
White Noise 100MHz 80MHz 60MHz 30MHz 20MHz 10MHz 5MHz
Arb.  1uHz~30MHz 1uHz~25MHz 1uHz~25MHz 1uHz~20MHz 1uHz~20MHz 1uHz~10MHz 1uHz~5MHz
Resolution 1uHz
Accuracy ±2ppm, 18~28
Sine Wave Spectrum Purity
Harmonic Distortion Typical0dBmDC-1MHz: <-60dBc; 1MHz-10MHz: <-55dBc; 10MHz-100MHz: <-50dBc
Total Harmonic Distortion <0.1% (10Hz-20kHz, 0dBm)
Spurious signal
(non-hormonic)
Typical(0dBm): 10MHz: <-65dBc;
>10MHz <-65dBc+6dB/spectrum phase
Phase Noise Typical(0dBm,10kHz offset,) 10MHz:  ≤-115dBc/Hz
Square
Rise/Down time <10ns <11ns <12ns <14ns <16ns <18ns <18ns
Overshoot <3%(100KHz, 1Vpp)
Duty Cycle 10MHz: 20.0%~80.0%;
10MHz~40MHz: 40.0%~60.0%;
 >40MHz: 50.0%
8.0%~92.0%
Non-symmetry 1% of period+5ns
Jitterrms Typical1MHz,1Vpp, 50Ω)≤5MHz: 2ppm+500ps; > 5MHz: 500ps
Ramp
Linearity 1%(1KHz, 1Vpp)
Symmetry 0%~100%
Pluse
Period 33.33ns~1Ms 40ns~1Ms 40ns~1Ms 50ns~1Ms 50ns~1Ms 100ns~1Ms 200ns~1Ms
Pulse  12ns 14ns 14ns 16ns 16ns 18ns 18ns
Leading Edge Time 8ns 9ns 10ns 10ns 11ns 11ns 12ns
Overshoot <3%(1VPP)
Jitterrms Typical1MHz, 1Vpp, 50Ω
5MHz 2ppm+500ps
> 5MHz 500ps
Arb.
Rise/Fall time Typical(1Vpp):<6ns
Jitter Typical1MHz, 1Vpp, 50Ω
5MHz 2ppm+500ps;
> 5MHz 500ps
Amplitude characteristic
Amplitude  Range 20MHz:1mVpp - 20Vpp; 60MHz:1mVpp -15Vpp; 80MHz:1mVpp -10Vpp;
90MHz:1mVpp - 5Vpp; 100MHz:1mVpp - 2Vpp
Accuracy Typical1kHz Sine, 0V deviation, >10mVpp, Auto); ±1% of setting ±2mVpp
Amplitude Flatness 10MHz:±0.1dB 60MHz:±0.2dB 100MHz:±0.4dB
Resolution 1mv or 4 digits
Impedance 50Ω
Offset Characteristic
Range |Voffset| < Vmax – Vpp/2
Accuracy ±(1% of setting + 5mV + 0.5% of amplitude
Modulation Characteristic
Modulation Type AM, FM,PM,2ASK,2FSK,2PSK,PWM
AM
Carrier Waveforms  Sine, Square, Ramp, Arb. (except DC)
Source Internal/External
Modulating Waveforms Sine, Square, Ramp, Noise, Arb
Frequency 1Hz~500KHz
Depth 0%~120%
FM
Carrier Waveforms Sine, Square, Ramp, Arb. (except DC)
Source Internal/External
Modulating Waveforms Sine, Square, Ramp, Noise, Arb
Frequency 1Hz~500KHz
Frequency Deviation 0~360
PM
Carrier Waveforms Sine, Square, Ramp, Arb. (except DC)
Source Internal/External
Modulating Waveforms Sine, Square, Ramp, Noise, Arb
Frequency 1Hz~500KHz
Frequency Deviation 0%~120%
2ASK
Carrier Waveforms Sine, Square, Ramp, Arb. (except DC)
Source Internal/External
Modulating Waveforms Square of 50% duty cycle
Code Rate 1Hz~500KHz
2FSK
Carrier Waveforms Sine, Square, Ramp, Arb. (except DC)
Source Internal/External
Modulating Waveforms Square of 50% duty cycle
Code Rate 1Hz~500KHz
2PSK
Carrier Waveforms Sine, Square, Ramp, Arb. (except DC)
Source Internal/External
Modulating Waveforms Square of 50% duty cycle
Code Rate 1Hz~500KHz
PWM
Carrier Waveforms Sine, Square, Ramp, Arb. (except DC)
Source Internal/External
Modulating Waveforms Sine, Square, Ramp, Noise, Arb.
Code Rate 1Hz~500KHz
Width Deviation 0% to 100% of Pulse Width
Burst Characteristic
Burst Count 2000000000
Gated Source External trigger
Trigger Source Internal, External or Manual
Sweep Characteristics
Direction linear
Type Up
Sweep time 280 000s
Hold/Return time 280 000s
Trigger Source Internal, External, Manual
Mark Falling Edge of Sync signal(programmable)
General Specifications
Interface USB host, USB Device, LAN optional
Display 7’’ 64K Color TFT Display, 800*480
Power Voltage 100-120VACRMS(±10%), 45Hz to 440Hz, CAT; 120-240VACRMS(±10%), 45Hz to 66Hz, CAT
Power Consumption <60W
Weight 3KG
